Specification | Standard Sectional Dimension (mm) | Web thickness (mm) | Flange thickness (mm) | Weight |
C4*4.5 | 102*40 | 3.20 | 7.50 | 6.70 |
C5*6.7 | 127*44 | 4.80 | 8.10 | 10.40 |
C6*8.2 | 152*48 | 5.10 | 8.70 | 12.22 |
C6*10.5 | 152*51 | 8.00 | 8.70 | 15.64 |
C7*9.8 | 178*53 | 5.30 | 9.30 | 14.60 |
C8*11.5 | 203*57 | 5.60 | 9.90 | 17.10 |
C10*15.3 | 254*65 | 6.10 | 11.10 | 22.80 |
C10*20 | 254*69 | 9.60 | 11.10 | 30.00 |
C10*25 | 254*73 | 13.40 | 11.10 | 37.00 |
C10*30 | 254*76 | 17.10 | 11.10 | 45.00 |
C12*20.7 | 305*74 | 7.20 | 12.70 | 30.80 |
C12*25 | 305*77 | 9.80 | 12.70 | 37.00 |
C12*30 | 305*80 | 13.0 | 12.70 | 45.00 |
