Designation | Specification Depth*flange width (mm) | Web thickness(mm) | Flange thickness (mm) | Weight (kg/m) |
IPEAA 80 | 78*46 | 3.2 | 4.2 | 4.95 |
IPEAA 100 | 97.6*55 | 3.6 | 4.5 | 6.72 |
IPEAA 120 | 117*64 | 3.8 | 4.8 | 8.36 |
IPEAA 140 | 136.6*73 | 3.8 | 5.2 | 10.05 |
IPEAA 160 | 156.4*82 | 4.0 | 5.6 | 12.31 |
IPEAA 180 | 176.4*91 | 4.3 | 6.2 | 14.94 |
IPEAA 200 | 196.4*100 | 4.5 | 6.7 | 17.95 |
