Designation | Specification Depth*flange width(mm) | Web thickness (mm) | Flange thickness (mm) | Weight (kg/m) |
IPE100 | 100*55 | 4.1 | 5.7 | 8.1 |
IPE120 | 120*64 | 4.4 | 6.3 | 10.4 |
IPE140 | 140*73 | 4.7 | 6.9 | 12.9 |
IPE160 | 160*82 | 5.0 | 7.4 | 15.8 |
IPE180 | 180*91 | 5.3 | 8.0 | 18.8 |
IPE200 | 200*100 | 5.6 | 8.5 | 22.4 |
IPE220 | 220*110 | 5.9 | 9.2 | 26.2 |
IPE240 | 240*120 | 6.2 | 9.8 | 30.7 |
IPE270 | 270*135 | 6.6 | 10.2 | 36.1 |
